Product model | ZWN-1250FP |
Nominal voltage | 12.8V |
Nominal capacity@25℃ | 50AH |
Nominal energy | 640WH |
Battery Cell type | Prismatic 50Ah |
Combination(*s*p) | 4S1P |
Maximum continuous charge current@25℃ | 50A |
Maximum continuous discharge current | 50A |
Internal resistance | ≤10mΩ |
Full charge voltage | 14.6V |
Discharge cut-off voltage | 10V |
Operating temperature range | charge:0℃~55℃,Discharge:-20℃~60℃,Storage:-20℃~45℃ |
Dimension(mm) | 152*65*94mm |
Weight(KG) | 1.7KG |
Terminal Type | F1 terminal/Screw terminal |
Cover seal type | Screw Seal / Sealant Seal (Optional) |
Water proof | IP65 |
Cycle life | 100% DOD Cycles @ 25℃,1C/1C:>2000times 80% DOD Cycles @ 25℃,1C/1C:>3000times 50% DOD Cycles @ 25℃,1C/1C:>5000times |
LCD display | Display voltage V / power% (Optional) |
Bluetooth | Bluetooth with mobile app (optional) |
Series and parallel function | Support series and parallel into 24V, 36V, 48V |
Heating function | Optional, suitable for applications in low temperature and extremely cold regions |
