Model: JLS-12150
Battery Type: LiFePo4
Battery Voltage: 12.8V
Battery Capacity: 150Ah
Cycle Life: 3000~5000 times
Application: Storage Energy, Solar Power Generator etc
Specification | |
Casing material | Battery Pack PC+ABS shell |
Nominal capacity | 150Ah |
Minimum Capacity | 148.0Ah |
Nominal Voltage | 12.8V |
Max. Charge Volt. | 14.6V |
Discharge cut-off voltage | 8V |
Standard charge current | 50A |
Standard discharge current | 50A |
Size | 520*267*220mm |
Battery Weight (Approx.) | 21.6Kg |
Battery binding post(mm) | +14mm*-14mm |
Internal resistance(Max, at 1000Hz.) | ≦80 mΩ |
Charging Temp | 0℃~45℃;32oF~113oF |
Discharging Temp | -20℃~60℃;-4oF~149oF |
Saving Temp | -20℃~45℃;-4oF~113oF |
Feature: Solar power, storage energy, recycle utilization, power generator, home energy storage
