Product model：ES-BOX5
Product specification：51.2V 200Ah
Cycle life：>6000 Cycles (80%DOD)
Weight：83Kg
Cell type：(LFP)
Standard charge voltage：58.4V
Max charge current ：100A
| Product model | ES-BOX5 |
| Product specification | 51.2V 200Ah |
| Nominal voltage | 51.2V |
| Nominal capacity | 200Ah |
| Cell type | (LFP) |
| Standard charge voltage | 58.4V |
| Max charge current | 100A |
| Discharge cut-off voltage | 40V |
| Max discharge current | 100A |
| Parallels Function | Support 15 units in parallels |
| Communication interface | RS485, RS232, CAN(Optional) |
| Cycle life | >6000 Cycles (80%DOD) |
| Charge temperature range | 0~65°C |
| Discharge temperature range | -20~65℃ |
| Colour | (Grey and white) |
| Dimensions | 673*618*193MM |
| Weight | 83Kg |
| Installation method | (Wall mounted) |
