Model: JLS4840
Battery Type: LiFePo4
Battery Voltage: 48V
Battery Capacity: 40Ah
Cycle Life: 2000~3000 times
Application: Robot
| Parameter | |
Casing material | Battery Pack PC+ABS shell |
Nominal capacit | 40Ah |
| Minimum Capacity | 39.5Ah |
| Nominal Voltage | 48V |
| Max. Charge Volt. | 55V |
Discharge cut-off voltage | 31.5V |
Maximum charging current | 20A |
Maximum discharge current | 40A |
| Size | 531*238*220 |
| Weight | 20.15Kg |
| Connector | 10AGW-50CM/ Anderson connector |
Internal resistance（Max, at 1000Hz.) | ≦60 mΩ |
Charging Temp | 0℃～45℃；32oF～113oF |
| Dicharging Temp | -20℃～60℃；-4oF～149oF |
| Storage Temp | -20℃～45℃；-4oF～113oF |
Feature: Long lifespan, environment friendly, with communication function
