Model:JLS-1210-NCM
Battery Type: NCM
Battery Voltage: 11.1V
Battery Capacity: 10Ah
Cycle Life: 500~800times
Application: Heating Bag
GenixGreen Patent No: CN207726027U
| Capacity（0.2C5A） | Nominal | 10.05Ah |
| Minimum | 9.96Ah | |
| Rated Voltage | 11.1V | |
| Max. Charge Voltage | 12.6V | |
| Discharge Cut-off Voltage | 8.9V | |
| Max. Charge Current | 3A | |
| Max. Discharge current | 6A | |
| Battery Size(max): | 170*173*25mm | |
| Battery Weight (Approx.) | 0.76KGS | |
| Battery Outlet Cable（mm） | 80mm | |
| Resistance（Max, at 1000Hz.） | ≤200 mΩ | |
| Temperature Setting Range | 70℃ . 75℃. 80℃. 85℃. 90℃ | |
| 5V USB Output | USB1： 1A。 USB 2： 2.1A | |
| Discharge Cable | 4 Cores connector, 2 cores is for detecting temperature signals | |
| Charge Cable | Canon male connector (1positive 2negative 3 empty) | |
| LCD display screen size | 40*20mm | |
| LCD display content | 1, the power digital display, 2, the current temperature gear display, 3, C / F display, two temperature specifications display | |
| Operation Temperature | Charge：0℃～45℃；32oF～113oF Discharge：-20℃～60℃；-4oF～149oF Storage：-20℃～45℃；-4oF～113oF | |
Feature: Quick Heating Transferring, High efficiency, long lifespan, Environmental Friendly
