5kwh Powerwall for solar energy storage system

Brand Name: Genixgreen / OEM

Battery Type: LiFePO4, Lithium ion battery Battery. 51.2V 100AN LiFePO4

battery Parallels: Available to make 8 parallels

Usage: appliances in home/office

Cycle life: 6000 times - 8000 times.

Warranty.5 years

Inquire Now Next Product

Product Description

Product parameter

Model	ES-BOX2
Battery Type	LiFePO4
Energy	5120Wh
Rated Capacity	100Ah
Rated Voltage	51.2V
Battery cell	3.2V 100Ah Pirsmatic Battery Cell
Configuration (SP)	16S1P
Disharge Cut-off Protect Voltage	40V
Charge Cut-off Protect Voltage	58.4V
Max. Charge Current	100A
Max. Discharge Current	100A
Communication Port	CAN, RS485
Compitable Inverter Brand	SMA, Growatt, Solax, Solis,DEYE,Sungrow, Sofar, Voltronic, Goodwe, etc.
Parallel	Max. 5 units in Parallels to get 25.6kwh.
Cycle life	100% DOD 3000 times
LWH (mm)	600510173
Net Weight (KG)	58KG
Cooling	Natural cooling
Environment	Indoor
Mounting options	Floor or wall mount
Discharge Temperature (℃)	-10℃~+60℃
Charge Temperature (℃)	0℃ ~+45℃
Storage Conditions	–20°C to 30°C (–4°F to 86°F) Up to 95% RH, non-condensing State of Energy (SoE): 25% initial
Maximum Elevation	3000 m (9843 ft)

5kwh Powerwall for solar energy storage system
