Nominal Voltage:51.2V
Nominal Capacity:100Ah
Nominal Energy:5.12kWh
Operating Voltage Range:40~58.4V
Standard Charging Current:100A
Standard Discharging Current:100A
Max. Continues Output power:5kW
All ln One Energy BOX (5KWH+3KW/5KW)
Parameters | Powerstation- 5kWh | |
Electrical | ||
Nominal Voltage | 51.2V | |
Nominal Capacity | 100Ah | |
Nominal Energy | 5.12kWh | |
Operating Voltage Range | 40~58.4V | |
Standard Charging Current | 100A | |
Standard Discharging Current | 100A | |
Max. Continues Output power | 5kW | |
Protection | ||
Over Charge | ✔ | |
Over Discharge | ✔ | |
Over Current | ✔ | |
Reverse Connection | ✔ | |
Short Circuit | ✔ | |
Temperature | ✔ | |
Physical | Physical | |
Dimensions | W710*D300*H670mm | |
Weight | ≈80kg | |
Inverter | ||
Power | 3200W(Pure Sine wave) | |
Solar Panel Input Spec. | 120V~450VDC, ≤2500W | |
Charging Temperature | 0℃~55℃ | |
Discharging Temperature | -20℃~55 | |
AC Output | 230V AC, 50/60HZ | |
Cycle Life* | 6000 @80% DOD, 25℃ | |
Certification | to be announced | |
Transfer time | ≤10ms typical (UPS); 20ms typical (Appliances) | |
Monitor | LCD display screen, APP Monitoring(Optional) |
