With cooling system ensures higher efficiency and longer battery cycle life
Variety of applications are supported such as peak-shift, peak-cut, frequency regulation, etc.
Highly integrated ESS for easy transportation and O&M All pre-assembled, no battery module handling on site
Multi level battery protection layers formed by discreet standalone systems offer impeccable safety
Battery System Side | ||
Model | HV-614.4V 100AH*2P | |
Rated voltage | 614.4V | |
Rated capacity | 200ah (0.2C) | |
Charge voltage | 681.6VDC (adjustable) | |
Discharge voltage | 537.6VDC | |
Rated working current | 100A (0.5C) | |
Max. working current | 160A (0.8C) | |
Rated power | 61KW | |
Max. output power | 100KW | |
Recommended DoD | 90% | |
Range of working temp. | -10~50°C | |
Working humidity range | 5-85%RH | |
Communication method | two way CAN2.0/RS485 | |
Working indicator | Blue:Power; Green:Running; Red:Alarm protection | |
Cycle life | 25±2°C, 0.2C/0.2C,EOL70% ≥ 6000 | |
Display method | 10 inch (LCD)/PC Software | |
Protective function | Voltage protection | Over charge and over discharge |
Temperature protection | Over temperature range protection | |
Current / Leakage protec | YES | |
Dielectric withstand volta | 1000VDC(not less than 1GΩ) | |
Dimension | 2000*2500*2500MM | |
Protection level | IP 65 | |
Product packaging | Container | |
PCS DC Input Side | ||
Voltage | 150-800VDC(614.4V) | |
Max. charge power |
50+50A | |
Max. discharge current | ||
PCS—PV Input side | ||
Max. photovoltaic power | 65000W | |
Max. photovoltaic voltage | 1000V | |
Starting voltage | 150V | |
MPPT range | 200-850VDC | |
Full load DC voltage | 450-850VDC | |
Rated DC input | 600V | |
PV input current | 36A+36A+36A+36A | |
PV input channels | 4 ways | |
communication method | two way CAN2.0/RS485 | |
PCS —AC output side | ||
Rated AC power | 50KW | |
Max. output power | 55KW | |
Output rated current | 75.8A | |
Max. output current | 83.3A | |
off-grid peak power | 1.5 times the rated power, 10S | |
Generator input/smart load/AC coupling current (A) | 75.8A | |
150A | ||
75.8A | ||
power factor | 0.8 lead/0.8 lag | |
Output Frequency/Voltage | 50/60Hz; 3L/N/PE 220/380, 230/400Vac | |
AC Phase | Three Phase | |
Highest efficiency | 97.6% | |
Rated efficiency | 97% | |
MPPT efficiency | 99.9% | |
Protective function | PV input lightning protection, anti-islanding protection, PV string input reverse polarity protection, insulation resistance detection, residual current monitoring device, output overcurrent protection, output short circuit protection, surge protection | |
Output voltage protection | DC Type II/AC Type III | |
Grid certification | CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98, VDE 0126-1-1, RD 1699, C10-11 | |
Safety certificate | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |
Working temp. range | -40~60℃, >45 ℃ Power down | |
Communication method | RS485/CAN | |
