Model:ES-BOX4
Cycle life:4000 times - 8000 times
Warranty:5 years
Nominal Voltage:51.2V
Nominal Capacity @25℃:200AH
Nominal Energy @25℃:10240WH
Dimension (mm):900X420X220MM
Communication Interface:RS485/ RS232 / CAN
Model | ES-BOX3 | EX-BOX4 |
Nominal Voltage | 51.2V | 51.2V |
Nominal Capacity @25℃ | 100AH | 200AH |
Nominal Energy @25℃ | 5120WH | 10240WH |
Battery Cell Type | 3.2V 100AH LiFePO4 Lithium iron phosphate battery | |
Configuration (*S*P) | 16S1P | 16S2P |
Max. Continous Charge Current @25℃ | 100A | 100A |
Max. Continous Discharge Current @25°C,10s | 100A | 100A |
Dimension (mm) | 600X400X220MM | 620X590X206MM |
Weight (KG) | 64KG | 105KG |
DC Resistance | ≤10mΩ | |
Full Charged Voltage | 58.4V | |
Discharge Cut-off Voltage | 40V | |
Operate Temperature Range | Charge: 0˚C~55˚C; Discharge: -20˚C~60˚C; Storage: -20˚C~45˚C | |
Humidity (non-condensing) | Max. 95% | |
Display | LCD | |
Communication Interface | RS485/ RS232 / CAN | |
Waterproof | IP65 | |
Cycle life | 4000 times - 8000 times | |
Service Life | 5-15 years | |
Warranty | 5 years |
